Frame: Hinged frame. The rear axle is rigid and the front axle is balanced. There is a hinged plug, a rigid welded frame made of high-quality steel plates and section steel. The bottom of the rear bogie is protected by a removable steel plate.

Driving speed: 1. Transmission (stepless) 0-8km/h; 2. Transmission (stepless) 0-20km/h;

Thrust: 65 kN

Gradient: 20°

Weight: 11400 kg

axle load: front: 4200 kg; Rear: 7200 kg;

Diesel engine:

Deutz, TCD4.1 type, Euro3, water-cooled;

Power: 2300 kW at 115 rpm; Exhaust system: equipped with muffler; Equipped with catalysts; exhaust gas sampling nozzles before and after the catalyst; Air intake system: filter with two-stage air purification: stage 1 - cyclone; Stage 2 – Dry air cleaner.

Diesel Engine Monitoring System: An engine monitoring unit that automatically shuts down the engine when the engine oil pressure is low or the engine temperature is high.

Fuel system: coarse and fine fuel filter with oil pan with ≈ 170 litres,

Drive mode: hydrostatic, front and rear axle drive separation. 2 forward/reverse gears are continuously shifted according to the load, all-wheel drive.

Axle: Rigid planetary axle with disc brakes, rotating in a sealed oil bath. Front axle type: Dana Spicer 113 Rear axle type: Dana Spicer 113 tank with manual filling pump and aerator, as well as return and suction filters;

Steering: Centrally articulated with oscillating front split shaft.

front split axle wheel steering angle ± 38/32 °;

Bridge swing angle ±10°;

Hinge rotation angle ±45°;

Hydraulic steering, engine idle steering, 2-acting steering cylinder.

Connector: DIN metric connector;

Electrical equipment: IP54 protection level; Voltage 24 V; 28V/80A alternator; Starter: battery 2x12 V 110 Ah; There are 4 headlights in the front and 2 in the rear;

Cab: Enclosed cab on ROPS/FOPS base. left door with sliding window; Heated by an engine with a fan and windshield nozzles, windshield with windshield wipers and washers. Adjustable driver's seat with anti-static upholstery, with shock absorbers, with seat belts. Conveniently located controls and controls. two rear-view mirrors; The door/toolbox/lid is locked with a key; Index: pressure gauge: brake circuit; Thermometers: engine oil, engine coolant, hydraulic oil. Annex:

Blade: Front Blade The blade is mounted on the front frame in front of the front axle The blade is raised and lowered by a hydraulic cylinder.

Blade width 2.100 mm;

Cutting depth 80 mm;

Medium blades; The blade is mounted on the front frame behind the front axle; hydraulic control of blade lifting, blade rotation and lateral movement;

 Blade width 3,054 mm; Depth of cut 310 mm; Rotation angle±45°; Lateral travel ±500 mm; 375 mm blade extension;

Fire extinguishing system: autonomous fire extinguishing system; Activated from the driver's control panel; manual fire extinguishers; Complete set: centralized lubrication system block; Safety Equipment: Yellow Pulse Beacon; sound signal when reversing;

Machine accessories: tool kits; Kit; 2 warning triangles; 2 wheel wedges; Package includes: spare tire; Tool; a set of parts with a service life of up to 2000 hours;
